This machine uses photosensitive resin plate or rubber plate as the printing plate. It is special design for the Web printing. It is ideal printing equipment for food bag, clothing bag, etc.
According to the base material width, the models are YTZ-4600, YTZ-4800, YTZ-41000,YTZ-41200,YTZ-41400 YTZ-41600 YTZ-41800 YTZ-42000. It can print the max four colors.
Performance and Features
1. Lifting and falling use hydraulic pressure with more power.
2. Hot and cold air box with double inlet air drying device make the drying speed higher, and more effective.
3. Automatic tension control device makes the feeding and discharging materials easier.
4. Aluminum pipe adopts oxidation treatment; it makes the transportation of materials easy and smooth.
5. Can choose manual or automatic to adjust the plate position, make the registration more accurate.
6. Easy to operate and more stable and higher speed (refer to the table as follows).
|
|
YTZ4600
|
YTZ4800
|
YTZ41000
|
YTZ41200
|
YTZ41400
|
YTZ41600
|
YTZ41800
|
YTZ42000
|
|
Max Effective Printing Width (mm)
|
580
|
780
|
980
|
1180
|
1380
|
1580
|
1780
|
1980
|
|
Max Base Material Width (mm)
|
600
|
800
|
1000
|
1200
|
1400
|
1600
|
1800
|
2000
|
|
Printed Matter Length (mm)
|
200---1250
|
|
Max Mechanical Speed (m/min)
|
100
|
|
Max Printing Speed (m/min)
|
10---80
|
|
Max Diameter of Roll Material (mm)
|
￠1000mm/￠1200mm/
|
|
Anilox Roller Mesh Number (Netted Stick) (piece)
|
80--600
|
|
Internal Diameter of Roll Core (mm)
|
￠76mm
|
|
Registration accuracy (mm)
|
±0.2mm
|
|
Plate Thickness(Both Side Adhesive Included ) (mm)
|
2.38mm(4mm Optional)
|
|
Main Motor (Kw)
|
2.2
|
3
|
3
|
4
|
|
Heating Power (Kw)
|
18
|
21
|
24
|
28
|
|
Fan Unit (Kw)
|
0.55+
|
0.75
|
1.1
|
1.5
|
|
Total Machine Power (Kw)
|
31
|
37
|
47
|
57
|
|
Machine Weight (T)
|
5
|
5.5
|
5.9
|
6.2
|
6.4
|
6.7
|
7
|
7.3
|
|
Overall Dimension （L*W*H） (m)
|
5.5*2.1*2.6
|
5.5*2.3*2.6
|
5.5*2.5*2.7
|
5.5*2.7*2.7
|
6.5*2.6*2.8
|
6.7*2.8*2.8
|
6.8*3.1*2.9
|
6.9*3.4*2.9
|
|
